powerCON TRUE1 - Schuko cordset rewirable

NEUTRIK^® cabels with re-wireable NEMA 5-15P plug to powerCON^® TRUE1^® and high-quality SJOOW or SJTOW cables. Ideally suited for stages and events.

Compliant with all relevant versions of IEC 60799.

Features & Benefits

Cord sets with NEMA 5-15P to powerCON^® TRUE1 female connectors
High-quality, rubber-insulated SJOOW cables (SJTOW cables available on request)
Available with AWG12 conductor cross section (AWG14 on request)
Fitted with powerCON^® connectors (NAC3F-TRUE1*), tested according to UL498 and UL 60320-1
Ruggedized powerCON^® connectors with Circuit Breaking Capacity (CBC)
High-quality NEMA 5-15P connectors
Rated IP20 for limited dust and water protection
Fully compliant with UL 817

Downloads

Article Varations

Article name	Details	Order code
NKPS10-ABA1-F0060	6 feet, SJOOW AWG12, NEMA 5-15P, powerCON® TRUE 1® TOP (f)	1027576
NKPS10-ABA1-F0100	10 feet, SJOOW AWG12, NEMA 5-15P, powerCON® TRUE1® TOP (f)	1036429
NKPS10-ABA1-F0250	25 feet, SJOOW AWG12, NEMA 5-15P, powerCON^® TRUE1^® TOP (f)	1027577
